Stencil Cleaning Solutions

SMT stencil cleaning solutions from Surclean — designed for performance and sustainability.

Surclean Stencil Cleaning Range

Designed for Performance and Sustainability

Consistent, reliable stencil printing is a prerequisite for high-quality surface mount technology (SMT) assembly. Poor stencil cleanliness directly increases defects, rework and yield losses. Surclean offers an engineered portfolio of stencil cleaning materials and chemistries that help manufacturers protect print quality, reduce downtime and lower total operating costs.

Surclean supplies cleaning solutions tailored for every stage of stencil maintenance — from manual spot-cleaning at the printer to fully automated under-stencil and offline cleaning systems. The range includes safer solvent blends engineered for fast, effective residue removal, and lint-free saturated and dry wipes suitable for manual wiping, hand-sprayer applications and automated paper-roll or wipe systems.

✓ Proven Effectiveness

Proven effectiveness on solder paste, adhesive and flux residues encountered in modern SMT processes.

✓ Greener Chemistries

A range of greener chemistries and low-VOC options that reduce environmental impact and regulatory risk.

✓ Optimised Formats

Product formats optimised for manual and automated cleaning operations — reducing cycle time and consumable costs.

✓ Technical Support

Technical support to help integrate cleaning solutions into existing IPC/J-STD process controls and supplier quality programs.

Surclean Product Range

Cleaning Solutions & Consumables

Six products covering every stage of stencil maintenance — from bulk liquid solvents to pre-saturated and dry wipe formats.

SC100-1L

SCREENCLEAN 100 STENCIL CLEANER 1L

Fast-acting, low-VOC stencil cleaning solvent in a ready-to-use 1L sprayer.

Screenclean 100 is a fast-acting stencil-cleaning solvent formulated to remove solder paste and most adhesives quickly and effectively. A Propylene Glycol Ether-based formulation, it dissolves and lifts solder paste, adhesives, resins and rosins quickly — even when residues have dried — and evaporates cleanly with minimal, non-tacky residue. It shows good compatibility with common elastomers, rubbers, industrial finishes and the screen adhesives used on mesh-backed framed stencils.

Specifications

Volume 1 Litre

Formulation Propylene Glycol Ether-based

Format Ready-to-use hand sprayer

Profile Low-VOC, biodegradable, non-bioaccumulative

Dissolves and lifts solder paste, adhesives, resins and rosins quickly — even when residues have dried
Low-VOC, non-ozone-depleting, biodegradable and non-bioaccumulative
Low toxicity, low odour and a high flash point for safer handling

Application: Manual cleaning between prints, supplied in a ready-to-use hand sprayer.

Enquire About This Product

SC100-5L

SCREENCLEAN 100 STENCIL CLEANER 5L

The same proven Screenclean 100 formulation in an economical 5L bulk container.

Specifications

Volume 5 Litres

Formulation Propylene Glycol Ether-based

Format Bulk container

Profile Low-VOC, biodegradable, non-bioaccumulative

Dissolves and lifts solder paste, adhesives, resins and rosins quickly — even when residues have dried
Low-VOC, non-ozone-depleting, biodegradable and non-bioaccumulative
Economical use rates with reduced solvent consumption for high-volume operations

Application: Bulk supply for automated stencil printers using paper-roll under-stencil cleaning systems, and for refilling hand sprayers.

Enquire About This Product

ES200-5L

ECOSOLVE 200 PERFORMANCE FLUX CLEANER 5L

High-performance solvent blend for stubborn flux deposits and uncured adhesives.

ECOSOLVE 200 is a high-performance solvent blend formulated for demanding precision cleaning tasks in electronics manufacturing and industrial settings. Designed to tackle stubborn residues such as flux deposits and uncured adhesives, ECOSOLVE 200 delivers enhanced solvency compared with conventional isopropyl alcohol (IPA) while maintaining compatibility with most plastics, rubbers and common elastomers.

Specifications

Volume 5 Litres

Format Liquid solvent blend

Evaporation Slower than IPA — extended wet contact time

Compatibility Most plastics, rubbers and elastomers

Superior cleaning power — dissolves heavy residue loadings including rework flux and SMD adhesives
Controlled, slower evaporation gives extended wet contact time for effective brush agitation
Safe for use on almost all common plastics, rubbers and elastomers used in electronics assemblies

Application: Removal of flux residues and white salts from PCBs, elimination of uncured and SMD adhesive residues during rework, and general degreasing and precision cleaning of electronic assemblies and components.

Enquire About This Product

SC100-PRO-200

SCREENCLEAN 100 PRO WIPES

Pre-saturated 70/30 IPA/DI wipes for fast, affordable routine cleaning.

SCREENCLEAN 100 PRO Wipes are an affordable, high-value cleaning solution designed for routine maintenance and quick cleanup tasks in workspaces, production benches, laboratories and office environments. Formulated to balance effective residue removal with safety and convenience, these wipes are ideal for operations where frequent, reliable surface cleaning is required.

Specifications

Solution 70% IPA / 30% Deionized Water

Sheet Size 200mm x 220mm

Count 200 sheets per tub

Container Foil-sealed, resealable pull-through lid

Pre-saturated with a 70/30 mixture of Isopropyl Alcohol (IPA) and deionized (DI) water for efficient removal of oils, flux residues, light greases and fingerprints
Low-lint, high-absorbency substrate provides good absorbency without leaving fibres or streaks on sensitive surfaces
Supplied in a tub of 200 perforated sheets (200mm x 220mm), easy to dispense for quick, controlled use

Application: General manufacturing, electronics assembly, cleanroom-adjacent tasks and routine workbench maintenance.

Enquire About This Product

SC100-ULTRA-200

SCREENCLEAN 100 ULTRAWIPES

Premium hydro-entangled wipes for high-performance stencil and residue removal.

SCREENCLEAN 100 ULTRAWIPES provide high-performance wipes designed for rapid, reliable removal of solder paste and adhesive residues from stencils and related surfaces. Each wipe is produced from a carefully engineered blend of virgin polyester and rayon, hydro-entangled to form a uniform, high-strength fabric that delivers excellent absorbency, tensile strength and abrasion resistance while minimising particle generation.

Specifications

Sheet Size 230mm x 150mm

Count 200 saturated sheets per tub

Material Virgin polyester/rayon, hydro-entangled

Application Automatic under-stencil systems / manual wiping

Rapid, reliable removal of solder paste and adhesive residues from stencils and related surfaces
Premium virgin polyester and rayon blend, hydro-entangled for a uniform, high-strength fabric
Excellent absorbency, tensile strength and abrasion resistance with minimal particle generation

Application: Under-stencil automatic cleaning systems and heavy-duty manual wiping.

Enquire About This Product

SC100-SUPER-300

SCREENCLEAN 100 SUPERWIPES

Premium dual-textured dry wipes for precision cleaning, including cleanroom use.

SCREENCLEAN 100 SUPERWIPES are premium, hydroentangled polyester-rayon wipes engineered for demanding cleaning tasks in electronics and precision manufacturing. Their construction delivers high wet strength and excellent resistance to linting, making them ideal for stencil cleaning, component preparation and general surface maintenance where contamination control is critical.

Specifications

Sheet Size 230mm x 230mm (9" x 9")

Count 300 dry sheets per pack

Type Dual-textured — smooth and embossed sides

Cleanroom Available airwashed, double-bagged (Class 100)

Premium hydroentangled polyester-rayon construction with high wet strength and excellent lint resistance
One side is ultra-smooth for gentle removal of residues from delicate plastics and glass optics
Reverse side features an embossed texture to enhance soil pickup on heavier deposits

Application: Stencil cleaning, component preparation and general surface maintenance — including cleanroom Class 100 environments.

Enquire About This Product

Why It Matters

Engineered for Modern SMT Production

For manufacturers seeking measurable yield improvements, lower operating costs and more sustainable cleaning options, Surclean provides practical, validated solutions you can deploy across the SMT assembly line.

Performance Benefits & Operational Savings

Surclean materials consistently improve PCB yields by removing solder paste, adhesives, flux residues and other process contaminants that degrade print definition and create defects. Improved cleaning reduces the frequency of printer adjustments and downtime, lowers scrap and rework rates, and extends stencil service life.

Meeting the Demands of Complex PCBA Designs

As PCBA designs evolve to smaller track widths and finer pitch components, residues such as flux, resins and microscopic process contaminants become harder to remove and more impactful to assembly yield. Surclean’s products are designed to meet these challenges by rapidly softening and dissolving residues so they can be removed without damaging fine apertures or delicate PCB finishes. Many OEMs and integrators now require incoming assemblies to meet IPC and J-STD cleaning standards, and Surclean chemistries and application methods are compatible with these requirements.

Flexible for Every Cleaning Workflow

Surclean supports every cleaning workflow: bench-top manual wipes and sprays for fast intervention, semi-automated under-stencil systems for inline printer maintenance, and high-throughput offline cleaning for bulk stencil or component processing. The portfolio is formulated to be compatible with common stencil materials, adhesives, rubbers and industrial finishes, enabling safe, repeatable cleaning across a broad set of production environments.

Take the next step

Order Surclean products or request more information

Contact our team for pricing, availability, technical data sheets and delivery on the complete Surclean stencil cleaning range.
